The next generation LG SW G2 membranes have achieved record-breaking salt rejection, improving the product

quality up to 45% compared with the conventional technology. With enhanced Thin Film Nanocomposite (TFN)

technology, LG SW G2 membranes can significantly reduce the cost of desalination.

LG SW R (High Rejection) membranes offer a combination of high rejection and low energy requirements to reduce

the total cost of desalination; suitable for medium to high salinity seawater applications

LG SW G2 Benefits

• Improved permeate quality without increasing operating pressure
• Reduced energy cost without sacrificing the permeate quality
• Reduced capital and operation costs for multi-pass SWRO systems

Operating Specifications:

• Max. Applied pressure 1,200 psi (82.7 bar)
• Max. Chlorine concentration < 0.1 ppm
• Max. Operating temperature 45°C (113°F)
• pH Range, Continuous (Cleaning) 2-11 (2-13)
• Max. Feedwater turbidity 1.0 NTU
• Max. Feedwater SDI (15 mins) 5.0
• Max. Feed flow 75 gpm (17 m3/h)
• Min. Ratio of concentrate to permeate flow for any element 5 : 1
• Max. Pressure drop (ΔP) for each element 15 psi (1.0 bar)
